Maximum Air Flow (FAD) at 1500 rpm | 710 m3/hour (415 cfm) |
Maximum Pressure | 1.5 bar (22 psi) gauge |
Maximum Vacuum Intermittent | 0.95 bar gauge (28 inches Hg) |
Maximum Vacuum Continuous | 0.80 bar gauge (24 inches Hg) |
Power absorbed at maximum pressure | 33 Kw (44 HP) at 1500 rpm |
Weight of bare shaft machine | 132 Kg (291 lbs) |
Speed range | 900 to 1500 rpm |
Features
- High capacity
- High vacuum
- Compact
- Lightweight
- Air cooled
- Oil lubricated
- Hardened bore to increase durability
- Drives : PTO/propeller shaft, hydraulic motor, diesel or electric
- Accessories : Full range available including reverse flow valve, oil tanks, suction line filter, strainer and silencers
